BATTERY PACKS FOR BUSINESS PROJECTS
Custom DroneBattery Packs
Industrial, agricultural and FPV packs. We help review your requirements, confirm the configuration and arrange samples.
Bulk MOQ: 100 pcsPaid samples for business projectsTypical sample preparation: 7–30 days
UAV BATTERY PACK OPTIONS
Choose the Pack
for Your Aircraft.Choose Your Pack Direction
Start with your aircraft type, then compare the pack examples below. Final specifications and availability are confirmed for your project.
01INDUSTRIAL UAV PACKS
Industrial, Mapping & Inspection DronesIndustrial, Mapping & Inspection
For surveying, mapping and inspection aircraft. Compare usable energy, weight and discharge limits for your mission.Compare usable energy, weight and current for surveying and inspection.
Shown: 22.2 V · 22,000 mAhPower and balance connections shown; interfaces confirmed per configuration.
02AGRICULTURE & HEAVY LIFT
Agricultural & Heavy-Lift DronesAgriculture & Heavy Lift
Pack options for agricultural and civil heavy-lift aircraft. Review take-off demand, mounting, cooling and charging turnaround.Review take-off demand, mounting, cooling and charging turnaround.
Agricultural example: 30,000 mAh · 12.6 kgVoltage, aircraft compatibility and charging limits confirmed for the selected pack.
03COMPACT FPV PACKS
FPV & Compact High-Power DronesFPV & Compact High Power
Compact pack options for professional FPV and small UAV programs. For drone brands and fleet orders from 100 pcs.For drone brands and fleet orders from 100 pcs.
Shown: 11.1 V · 450 mAh · 3S1P22 × 18 × 66 mm (H × W × L) · 40 g · XT30
Cell Options for Drone Battery Packs
Compare cell weight, capacity and continuous discharge current as a starting point for your UAV battery pack.
Pouch cell formats shown for reference
| Cell reference | Format | VoltageV | Min. capacityAh | Cont. chargemax · A | Cont. dischargemax · A | Dimensionsmm | Weight | Specific energyWh/kg | Cycle testConditions as listed |
|---|---|---|---|---|---|---|---|---|---|
| 7759156 | Pouch | 3.85 | 30 | 6 | 60 | 7.7 × 59.0 × 156.0 | 190 g | 608 | 5 cycles · ≥80%0.2C / 1C · 2.5V–4.50V |
| 5859156 | Pouch | 3.85 | 22 | 4.4 | 44 | 5.8 × 59.0 × 156.0 | 140 g | 605 | 5 cycles · ≥80%0.2C / 1C · 2.5V–4.50V |
| 5074172 | Pouch | 3.84 | 22 | 4.4 | 66 | 5.0 × 75.0 × 174.0 | 156 g | 542 | 10 cycles · ≥80%0.2C / 1C · 3.0V–4.50V |
| 6059156 | Pouch | 3.84 | 20 | 4 | 60 | 6.0 × 59.0 × 156.0 | 144 g | 533 | 10 cycles · ≥80%0.2C / 1C · 3.0V–4.30V |
| 7250130 | Pouch | 3.80 | 15 | 3 | 75 | 7.2 × 50.0 × 130.0 | 119 g | 479 | 10 cycles · ≥90%0.2C / 1C · 3.0V–4.30V |
| 7074172 | Pouch | 3.80 | 30 | 6 | 90 | 7.0 × 75.0 × 174.0 | 245 g | 465 | 10 cycles · ≥90%0.2C / 1C · 3.0V–4.30V |
| 7650130 | Pouch | 3.80 | 15.7 | 3.1 | 62.8 | 7.6 × 50.0 × 130.0 | 131 g | 455 | 20 cycles · ≥95%0.2C / 1C · 3.0V–4.30V |
| 4150130 | Pouch | 3.80 | 8 | 1.6 | 24 | 4.1 × 50.0 × 130.0 | 68 g | 447 | 20 cycles · ≥95%0.2C / 1C · 3.0V–4.30V |
| 8074250 | Pouch | 3.80 | 52 | 10.4 | 208 | 8.0 × 75.0 × 250.5 | 470 g | 420 | 20 cycles · ≥95%0.2C / 1C · 3.0V–4.30V |
| 10674172 | Pouch | 3.60 | 30 | 30 | 150 | 10.6 × 75.0 × 174.0 | 301 g | 359 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 10287188 | Pouch | 3.60 | 39 | 39 | 195 | 10.2 × 89.0 × 189.0 | 395 g | 355 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 10690192 | Pouch | 3.60 | 39 | 39 | 195 | 10.6 × 90.0 × 192.0 | 430 g | 327 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 6964124 | Pouch | 3.50 | 11 | 5.5 | 11 | 6.9 × 65.0 × 125.0 | 119 g | 324 | 300 cycles · ≥80%0.33C / 2C · 2.5V–4.2V |
| 9087188 | Pouch | 3.60 | 31 | 31 | 155 | 9.0 × 89.0 × 189.0 | 346 g | 323 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 105105230 | Pouch | 3.60 | 52 | 52 | 260 | 10.5 × 105.0 × 230.0 | 583 g | 321 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 10674172 | Pouch | 3.60 | 28 | 28 | 140 | 10.6 × 75.0 × 174.0 | 316 g | 319 | 500 cycles · ≥80%1C / 3C · 2.6V–4.2V |
| 11087188 | Pouch | 3.60 | 35.5 | 35.5 | 177.5 | 11.0 × 89.0 × 189.0 | 412 g | 310 | 500 cycles · ≥80%1C / 3C · 2.6V–4.25V |
| 11090192 | Pouch | 3.58 | 36 | 36 | 180 | 11.0 × 90.0 × 192.0 | 423 g | 305 | 500 cycles · ≥80%1C / 3C · 2.6V–4.25V |
| 119105230 | Pouch | 3.58 | 55 | 55 | 275 | 10.9 × 105.0 × 230.0 | 650 g | 303 | 500 cycles · ≥80%1C / 3C · 2.6V–4.25V |
| 110105230 | Pouch | 3.58 | 50 | 50 | 250 | 11.0 × 105.0 × 230.0 | 595 g | 301 | 500 cycles · ≥80%1C / 3C · 2.6V–4.25V |
| 104770 | Pouch | 3.60 | 5 | 5 | 35 | 10.0 × 47.0 × 70.0 | 60 g | 300 | 500 cycles · ≥80%1C / 3C · 2.8V–4.2V |
| 10674172 | Pouch | 3.58 | 25.5 | 25.5 | 127.5 | 10.6 × 75.0 × 174.0 | 305 g | 299 | 500 cycles · ≥80%1C / 3C · 2.6V–4.25V |
| 7664124 | Pouch | 3.58 | 11 | 22 | 55 | 7.6 × 65.0 × 125.0 | 135 g | 292 | 500 cycles · ≥80%2C / 3C · 2.6V–4.20V |
| 947665 | Pouch | 3.60 | 6.25 | 9 | 32 | 9.4 × 76.0 × 65.0 | 90 g | 250 | 400 cycles · ≥80%1.5C / 5C · 2.8V–4.20V |
| 804770 | Pouch | 3.60 | 4 | 6 | 35 | 8.0 × 47.0 × 70.0 | 60 g | 240 | 300 cycles · ≥80%0.5C / 5C · 2.8V–4.2V |
| 93161260 | Pouch | 3.72 | 50 | 100 | 150 | 9.3 × 161.0 × 260.0 | 841 g | 221 | 1500 cycles · ≥80%1C / 1C · 2.5V–4.3V |
| 103105230 | Pouch | 3.72 | 30.5 | 76.25 | 183 | 10.3 × 105.0 × 230.0 | 516 g | 220 | 1500 cycles · ≥80%1C / 1C · 2.5V–4.3V |
| 104136260 | Pouch | 3.70 | 45 | 90 | 135 | 10.4 × 136.0 × 260.0 | 764 g | 218 | 1000 cycles · ≥80%1C / 1C · 2.5V–4.3V |
| 9690192 | Pouch | 3.72 | 20.5 | 51.25 | 123 | 9.6 × 90.0 × 192.0 | 353 g | 216 | 1000 cycles · ≥80%1C / 1C · 2.5V–4.3V |
| 9264124 | Pouch | 3.70 | 8 | 16 | 24 | 9.2 × 65.0 × 125.0 | 149 g | 199 | 1000 cycles · ≥80%1C / 1C · 2.5V–4.3V |
These specifications describe individual cells. Pack voltage, capacity, current and weight depend on the complete pack configuration.
Capacity shown is minimum capacity. Dimensions: pouch T × W × L. “—” means not specified.
Cycle tests show the stated capacity retention and test conditions; they are not directly comparable across different conditions. Models 9264124, 104136260, 9690192, 103105230 and 93161260 are listed in the source for electric motorcycles and electric tricycles; suitability for a UAV battery pack requires confirmation. Dimensions for these five models are maximum values.
HELP WITH PACK SELECTION & CONFIGURATION
We Help Match the Pack
to Your Aircraft.
Bring us your existing battery or target requirements. Our engineering review helps narrow the configuration before you commit to samples or a bulk order.
Power & Capacity
We review voltage, capacity and working current to identify suitable pack options for your aircraft.
Size & Installation
We check dimensions, weight limits and mounting space against the aircraft requirements you provide.
Connections & Charging
We confirm connector type, wiring and charging requirements for the selected pack configuration.
Protection & Communication
Where needed, we review protection, monitoring and communication options with our partner factory. Compatibility is confirmed for your project.
No complete specification yet? Start with a photo of your current battery and its application.
ORDERING WITH MINGLONG
From Samples
to Bulk Supply.
Minglong handles engineering review and pre-shipment inspection. Your packs are produced at our partner factories in China.
Bulk From 100 pcs
Small sample quantities are available for business projects before a bulk order.
Paid Samples
Typical preparation: 7–30 days, depending on cell stock and build complexity. Sample fees may be credited toward qualifying bulk orders; terms are confirmed in your quotation.
Pack Documents
UN38.3 and MSDS are provided for our battery packs. Model-specific documents are confirmed in your quotation.
Price & Delivery
We quote against the agreed configuration, quantity and destination, with lead time and shipping terms.
Bulk production follows sample approval. Our team also coordinates shipping.
START YOUR BATTERY ENQUIRY
Tell Us About
Your Battery Order.
Our team will review suitable pack options and confirm sample arrangements, pricing and lead time.
You can enquire before every specification is final.
THREE DETAILS TO GET STARTED
- Your aircraft and application
- A battery photo or the specifications you have
- Quantity for this order — samples or bulk
